Menu Maps

continued next page
Run Screen → Menus → Sensor Setup →
Aux 1 ‐ 6 (Analog 0‐1v, 0‐5v, 4/20ma)
Sensor Setup
Aux 1 (Disabled) (4/20ma)
Aux 2 (Disabled) (4/20ma)
Aux 3 (Disabled) (4/20ma)
Aux 4 (Disabled) (4/20ma)
Aux 5 (Disabled) (4/20ma)
Aux 6 (Disabled) (4/20ma)
Probe (Disabled)
Control Mode (Set Point)
T
Set Point
PID/PWM
Alarms (Disabled)
Hold Off (15 Sec)
1‐255
Time Units (Sec)
T
Sec
Min
Hours
Alarm Low (0)* (Suffix)
Relay (Disabled)
Alarm Low (Disabled)
Instrument (Local Machine)
Relay (Relay 1)
T
Relay1 y
Relay2
Relay 3
Relay 4
Relay 5
Relay 6
Relay 7
Relay 8
Set Point control only Range Low (250)* (Suffix)
Relay (Disabled)
Range Low (Disabled)
Instrument (Local Machine)
Relay (Relay 1)
T
Relay1
Relay2
Relay 3
Relay 4
Relay 5
Relay 6
Relay 7
Relay 8
Set Point (25.0 c)
Menu Maps
Run Screen → Menus → Sensor Setup → Aux 1 ‐ 6 (Analog 0‐1v, 0‐5v, 4/20ma) continued from previous page
Sensor Setup
PID/PWM control only Control Up/Down (Rising)
T
Rising
Falling
PID/PWM control only P.I.D. Interval (100.00)
1.00 to 999.90
PID/PWM control only P.I.D. Reset Interval (20.00)
PID/PWM control only P.I.D. Gain (2000)
PID/PWM control only P.I.D. Relay (Disabled)
Range Low (Disabled)
Instrument (Local Machine)
Relay (Relay 1)
T
Relay1
Relay2
Relay 3
Relay 4
Relay 5
Relay 6
Relay 7
Relay 8
Set Point control only Range High (750)* (Suffix)
Relay (Disabled) Relay (Disabled)
Range High (Disabled)
Instrument (Local Machine)
Relay (Relay 1)
T
Relay1
Relay2
Relay 3
Relay 4
Relay 5
Relay 6
Relay 7
Relay 8
Alarm High (1000)* (Suffix)
Relay (Disabled)
Alarm High (Disabled)
Instrument (Local Machine)
Relay (Relay 1)
T
Relay1
Relay2
Relay 3
Relay 4
Relay 5
Relay 6
Relay 7
Relay 8
