Menu Maps
System
Communication
Ethernet (Not Available)
DHCP (Enabled)
IP Address (192.168.168.100)
Subnet Mask (255.255.255.0)
Gateway (192.168.168.1)
Port (10001) 1‐65535
DNS Address (192.168.1.1)
Email Address ( )
Email Address ( )
Email Address ( )
CC/Email Address CC
Network (Master)
Master
Slave 1‐31
Termination Relay (Enabled)
Run Screen → Menus → System Menu →
Communication
Send Test Email Msg (Not Available)
"Email test has been placed in the queue"
Email Retry Delay (Not Available) (15)
1‐255
Time Units (Not Available)
�
Sec
Min
Hours
Baud Rate �
Default Baud Rate
9600
14400
19200
38400
57600
115200
Force Serial Port (Disabled)
Menu Maps
System
Data Logging
Data Logging
Data Logging (Enabled) (1 Hour)
Logging Interval
Time units
T
Sec
Min
Hours
Event Logging (Enabled)
Clear Logs
T
Data
Events
Data and Events
"Are You Sure?"
Run Screen → Menus → System Menu →
Data Logging
System
Configure AUX
Aux 1 ‐ 6 (Disabled) (Name)
Probe Name ( )
Input Type (4/20ma)
�
Digital
0‐v
0‐5v
4/20ma
*Temperature
**Temp Source
�
Aux Port
ODO Probe
*Suffix ( )
*Min (0 )
‐10000 to 10000
*Max (1000)
‐10000 to 10000
*Input Scaling Min (4)
‐10000 to 10000
*Input Scaling Max (20)
‐10000 to 10000
*Display Format (0)
�
0
0.0
0.00
Run Screen → Menus → System Menu → Configure Aux
*Aux analog only (not available for
aux temperature or aux digital) *Temperature available
on aux 3‐6 only
**5500D‐1, 5500D‐2, 5500D‐4 aux
temperature only
