Galaxy Power System 4848/100 with Dual Rectifier Shelf
Issue 5 September 2011
Troubleshooting Millennium Systems 13 - 1
13
Troubleshooting Millennium
Systems
Introduction
In This Section
This section provides information for locating and interpreting visual
indicators to help identify problems.
Preparation
Read Section 12, Troubleshooting Preparations, thoroughly before
proceeding.
Technical
Assistance
When visual indicators do not identify a defective part, notify Lineage
Power Technical Support.
