Galaxy Power System 4848/100 with Dual Rectifier Shelf
Issue 5 September 2011 Specifications 9 - 5
Physical
Width 265 mm (10.4 in.) rear of unit
Height 210 mm (8.25 in.) rear of unit
Depth 470 mm (18.2 in.) overall, less connector
Weight LTA - 17 kg (37 lbs) LTB - 15 kg (33 lbs)
Environmental
Efficiency - Typical From 100Adc to 220Adc
595LTA 595LTB
96% 95.5%
Storage Temperature -40°C - +85°C
Storage Relative Humidity 5% - 90%
Altitude -50 to 4000 meters (Note: For altitudes above 1500 meters,
derate the temperature by 0.656° Celsius per 100 meters.)
Audible Noise < 60dBA at room temperature, mounted in cabinet
Heat Release Per Rectifier:
54Vdc, 160Adc
54Vdc, 200Adc
54Vdc, 220Adc 595LTA 595LTB
270W (920 BTU / hr) 360W (1,240 BTU / hr)
450W (1,550 BTU / hr) 510W (1,750 BTU / hr)
560W (1,930 BTU / hr) 630W (2,150 BTU / hr)
Standards Compliance
Safety • UL Recognized (US and Canada) and VDE
• UL1950, EN60950/IEC950, and CSA 234/950 (tested for
SELV output)
Electromagnetic Compliance:
Emission and Immunity • EN55022 (CISPR22) Radiated/conducted emission Class A
• FCC Part 15 Class A
• IEC/EN 61000-4-2 ESD levels 3 and 4
• IEC/EN61000-4-3 Radiated Immunity, 10Vm
• IEC/EN61000-4-4 Electrical Fast Transients/Burst, level 4
• IEC/EN 61000-4-5 Lightning Surge, level 4
CE Marking CE marked per European Union Council directives: Low-voltage
Directive (73/23/EEC) as amended by CE Marking Directive (93/
68/EEC)
Table 9-C: Rectifier Display Messages and LEDs
State Display Message LED Illuminated
Normal Current On
Output Limited Current LIM
Manual Standby Blank STBY
Remote Standby (Shutdown) tr STBY
Output Breaker Open CB ALM
Interlock Open ILC ALM
AC Fail ACF None
Phase Fail PF None
OverTemperature Shutdown tA ALM
Output Under Voltage Shutdown LO ALM
High Voltage Shutdown HO ALM
Internal Failure LS, ICS, IP5, IP6, IP7, SEN, FSE, InF ALM
Table 9-B: 595LT Series S2:x Rectifier Specifications (Continued)
