Galaxy Power System 4848/100 with Dual Rectifier Shelf
9 - 6 Specifications Issue 5 September 2011
AC Input Panels
Table 9-D: AC Panels
Vac AC Feeds Rectifiers ED83142-30 H569-434GPS4848/100
AC Circuit Breaker Panels - 595 Rectifiers
208/240 2 4 3 20, 220
208/240 2 6 4 21
480 1 4 2 22
480 2 6 4 23
65KIC 480 2 4 10 70, 270
65KIC 480 2 6 11 71
AC Terminal Strip Panels- 595 Rectifiers
208/240 4 4 5 24, 224
208/240 6 6 5 25
208/240 8 8 18 129, 131
480 4 4 5 26, 226
480 6 6 5 27
480 8 8 18 128, 130
AC Circuit Breaker Panels - 595LT Rectifiers
208/240 2 4 3 320, 420
208/240 2 6 4 321, 421
208/240 4 12 25 335
480 1 4 2 322
480 2 6 4 323
480 4 12 24 334
65KIC 480 2 4 10 370, 470
65KIC 480 2 6 11 371, 471
AC Terminal Strip Panels - 595LT Rectifiers
208/240 4 4 5 324
208/240 6 6 5 325
208/240 8 8 18 331
208/240 12 12 26 329
208/240 14 14 26 333
480 4 4 5 326
480 6 6 5 327
480 8 8 18 330
480 12 12 26 328
480 14 14 26 332
Distribution Only Panels, no ac
- None 28
- None 29
