Galaxy Power System 4848/100 with Dual Rectifier Shelf
Issue 5 September 2011 List of Figures - 3
Figure 7-8: H569-434 G60/61/65/66 (ED83143-31 G71) 
600A DC Distribution Panel 7-5
Figure 7-9: H569-434 G67 (ED83143-31 G22) 
600A DC Distribution Panel 7-6
Figure 7-10: H569-434 G68 (ED83143-31 G21)

1200A DC Distribution Panel 7-6
Figure 7-11: H569-434 G96 (ED83143-31 G15) 
510A DC Distribution Panel 7-7
Figure 7-12: H569-434 G97 (ED83143-31 G16) 14-Position, and
H569-434 G98 (ED83143-31 G17) 22-Position DC Distribution
Panel
7-7
Figure 7-13: H569-434 G54 (ED83143-31 G54) 5-Position DC Dis-
tribution Panel 7-8
Figure 7-14: H569-434 G58 (ED83143-31 G58) 6-Position GMT DC
Distribution Panel 7-8
Figure 7-15: H569-434 G59 (ED83143-31 G56) 2-Position Fuse Dis-
tribution Panel 7-9
Figure 11-1: Installing a Rectifier in a Rectifier Shelf 11-4
Figure 11-2: Rectifier Fan Replacement 11-7
Figure 12-1: Location of Cabinet Alarm Light and Controller 12-2
Figure 12-2: Millennium Controller Display 12-5
Figure 12-3: Millennium Controller Fuses and Circuit Boards 12-5
Figure 12-4: Rectifier Display 12-6
Figure 12-5: Low Voltage Battery Disconnect 
Contactor Control Switches 12-7
Figure 12-6: AC Input Panel and Rectifier Positions, 6 Rectifiers
12-8
Figure 12-7: AC Input Panel and Rectifier Positions, 12 Rectifiers
12-9
Figure 12-8: DC Distribution Panel 12-10
Figure 12-9: Low Voltage Load Disconnect Contactor 
Control Switches 12-11
