Illustration, Illustration 1-2 – GE Industrial Solutions GPS 4848_100 Users Guide (dual rectifier shelf) User Manual
Page 18
Galaxy Power System 4848/100 with Dual Rectifier Shelf
1 - 2 Introduction
Issue 5 September 2011
GPS 4848/100, continued
Illustration
Figure 1-1 is an isometric view of the GPS 4848/100 with a Millennium
Controller.
Figure 1-1: GPS 4848/100 With Millennium Controller
Galaxy
Millennium
Controller
BLJ3
Terminal
Board
Battery Connection Panel
AC Panel
595LT Series
220A Rectifiers
DC Distribution
