Galaxy Power System 4848/100 with Dual Rectifier Shelf
9 - 2 Specifications Issue 5 September 2011
Physical
Width, Depth 600 mm, 600 mm (23.6 in. x 23.6 in.)
Weight (approximate, per cabinet) 250 kg (551 lbs.)
Height (cabinet only) 2134 mm (84.0 in.)
Height (cabinet with link bus bar) 2274 mm (89.5 in.)
Environmental
Heat Release, per cabinet 
(including 1% cabinet loss)
Number of Rectifiers
4
5
6
7
8
10
12
14
per Rectifier
at 54Vdc, 200Adc
595LTA S2:x 595LTB S2:x
2,240W (7,700 BTU / hr) 2,480W (8,500 BTU / hr)
2,800W (9,600 BTU / hr) 3,100W (10,600 BTU / hr)
3,360W (11,500 BTU / hr) 3,720W (12,700 BTU / hr)
3,920W (13,400 BTU / hr) 4,340W (14,900 BTU / hr)
4,480W (15,300 BTU / hr) 4,960W (17,000 BTU / hr)
5,600W (19,200 BTU / hr) 6,200W (21,200 BTU / hr)
6,720W (23,000 BTU / hr) 7,440W (25,500 BTU / hr)
7,870W (26,800 BTU / hr) 8,680W (29,700 BTU / hr)
560W (1,900 BTU / hr) 620W (2,120 BTU / hr)
Operating Temperature 0°C to 40°C
Operating Relative Humidity 5% - 95%
Units Per Cabinet with Controller
Rectifiers 595LTA / 595LTB: 0 - 12; 595A / 595B: 0 - 6
Controller 1
Battery Modules 0 - 3
DC Distribution 1 - 6 
(maximum of 5 with battery disconnect)
Units Per Cabinet without Controller
Rectifiers 595LTA / 595LTB: 0 - 14; 595A / 595B: 0 - 7
Battery Modules 0 - 1
DC Distribution 1 - 6 
(maximum of 5 with battery disconnect)
Table 9-A: Galaxy Power System 4848/100 Specifications (Continued)
