4-28
•
Chapter 4 Configuring an AVDV Series Drive GEH-6405A Toolbox for an AVDV Series Drive
Wizards
A wizard is an interactive
Help utility that guides the
user through each step of a
particular task, such as Drive
Commissioning.
The Wizard list can vary with
each product, but there is
always a Offline Basic
Commissioning Wizard.
The AVDV Series drive contains wizards that guide you through the setup of a
drive. Wizards display a series of dialog boxes that prompt the user for drive
configuration information. This information is also used as a basis to perform
additional tests and tune-ups on the drive.
Note The Offline Basic Commissioning Wizard or the Offline Advanced
Commissioning Wizard should be the first step when setting up a new drive.
À To perform a wizard
w
From the Edit menu, choose Wizards , or click . The following list of
wizards displays.
Choose Wizard
The Offline Basic
Commissioning Wizard
or the Offline Advanced
Commissioning Wizard
should be the first step
when setting up a new
drive.
The following dialog box is an example of the Offline Basic Commissioning
Wizard. Enter a value in each field, unless you are instructed otherwise.
Click here to obtain
interactive Help on
each field.
