GEH-6405A Toolbox for an AVDV Series Drive Chapter 4 Configuring an AVDV Series Drive
•
4-7
Validating the Drive
Also, items in the hierarchy
that had problems during
validation will display red
after the validation. Validation checks for errors that might prevent successful operation of the drive. If
the configuration needs to be validated, items in the Outline View displays in red.
Note In most cases, the configuration is automatically validated.
Or click
À To validate the drive configuration
w From the Drive menu, choose Validate .
The validation results display in the Log View at the bottom of the toolbox Work
Area screen.
Entering Job Specific Information
Each wizard dialog box
contains a Help button. Once a new drive has been created and the properties are modified, you must enter
job specific data, such as motor hp, motor amps, and motor speed. This information
can be entered in a new configuration using the menus or the Offline Commissioning
Wizards (refer to the section, Wizards). A wizard is an interactive Help utility that
guides the user through each step of a particular task, such as drive commissioning.
Each configuration depends
on application requirements.
For more information,
contact Product Service
Engineering at
+ 1 540 387 7597 or Fax at
+ 1 540 387 8606
(replace + with the
international access code).
À To configure the drive offline
1. From the Edit menu, choose Wizards.
2. Choose the Offline Basic Commissioning Wizard.
Note Entering the Offline Basic Commissioning wizard information and
performing the applicable tune ups should be sufficient to configure the drive for
basic operation.
