4-16
•
Chapter 4 Configuring an AVDV Series Drive GEH-6405A Toolbox for an AVDV Series Drive
Device Menu
The Device menu allows you to manage the drive with the following commands:
Or click
Validate makes certain that drive configuration does not contain errors.
Or click
Online/offline toggles to start or end communications between the toolbox and the
current drive.
Or click
Download Parameter Values to Drive sends the values of all the parameters
from the loaded drive configuration files to the current drive.
Download Parameters (include Service Parameters) sends the current
parameter set from the loaded drive configuration files including the factory Service
parameters.
Or click
Upload Parameter Values from Drive reads all the parameter values from the
current drive and provides the option of replacing the values in the currently loaded
drive configuration file in the toolbox.
Save Parameters saves the current active set of parameter values in the drive to
permanent storage
Reset Faults resets all faults that are currently active in the drive.
Download Network Configuration downloads the active network configuration.
Upload Network Configuration uploads the active network configuration.
Load Default Values loads the factory defaults in the drive and the currently
loaded drive configuration file in the toolbox. This selection requires the drive to be
online. The drive loads factory settings only when the drive is disabled.
