Pattern and version – GE Industrial Solutions Control System Toolbox For AV-300, DV-300, AV-300i (AVDV Series) Drives User Manual
Page 33
GEH-6405A Toolbox for an AVDV Series Drive
Chapter 4 Configuring an AVDV Series Drive
•
4-3
Pattern and Version
Pattern
Choose a Version.
Click OK.
The Select Product
Configuration dialog box
displays.
Select a configuration file
that sets the values for
the particular bridge size
being configured. Obtain
this number from the
drive nameplate on the
drive being configured.
