35

The following table once again explains the behavior of the ECG for
different switching actions:

Action

TouchDIM

Short press
(status: switched off)

TDI Mode I: switches on to last value before

switch-off

TDI Mode II: switches on to last double-click

value

Short press
(status: switched on)

Switch-off and store value for next switch-on in

TDI Mode I

Long press
(status: switched off)

Switch on and fade from min upwards

Dimming as long as button is pressed

Long press
(status: switched on)

Dimming fades upwards or downwards (de-

pending on pending toggle or logic function)

Double-click
(status: switched off)

Swap to TDI Mode I ( = auto memory of the

switch-on value), confirmation: switch-on and

dimming to maximum brightness

Double-click
(status: switched on & dim-
ming in the last 3 s)

Swap to TDI Mode II (switch-on value = double-

click value), confirmation: flashing and dimming

to double-click value

Double-click
(status: switched on & no
dimming in the last 3 s)

Holiday mode; only in combination with LMS

sensors (see www.osram.com/ecg-lms)

Power failure
(status switched off)

Remains switched off

Power failure
(status switched on)

Switches on to …

TDI Mode I : last value before power outage

TDI Mode II : last value before power outage

Table

4:

Behavior of the ECG for different switching actions, TDI =

TouchDIM interface
