Airborne Enterprise WLNN EVB Users Guide
10.0 Using the Web Interface
The Airborne Device Server includes a web interface that provides access to module
status, parameter modification and certificate and configuration file management. To use
the web interface follow the steps outlined in section 8.0 to establish the IP address of the
module. Once the IP address is known open a web browser and enter the IP address of
the module in the URL window.
The web interface currently supports Internet Explorer v6.0 thru 8.0, Firefox v3.x, Opera
v9.6+ and Chrome v1.0+.
When the authentication request is returned enter:
FIGURE 22 - WEBSITE LOGIN
Username: dpac
Password: dpac
After successfully authenticating with the module, you will be logged into the web server
and allowed to browse and update module settings if required. A quick overview of the
web interface follows.
10.1 Navigation Bar
FIGURE 23 - WEBSITE NAVIGATION BAR
