Airborne Enterprise WLNN EVB Users Guide
5.0 Feature Description
The following section provides detailed descriptions of the various connections, switches
and indicators provided by the Airborne Evaluation Board.
5.1 ANT1
This is one of two antenna connections available on the Evaluation board.
TABLE 3 - ANT1 CONNECTORS
Designator Connector Description
CN9 RP-SMA
Antenna connection requires antenna with RP-SMA
connector.
Impedance: 50Ω
CN10 U.FL
Coaxial connector to Airborne Device Server antenna
connector. Requires U.FL to U.FL coaxial cable
(included in kit). Must be connected to either J1 or J2
of Device Server Module.
Impedance: 50Ω
5.2 ANT2
This is one of two antenna connections available on the Evaluation board.
TABLE 4 - ANT2 CONNECTORS
Designator Connector Description
CN11 RP-SMA
Antenna connection requires antenna with RP-SMA
connector.
Impedance: 50Ω
CN12 U.FL
Coaxial connector to Airborne Device Server antenna
connector. Requires U.FL to U.FL coaxial cable
(included in kit). Must be connected to either J1 or J2.
Impedance: 50Ω
5.3 BT1
This section allows four (4) 1.5VDC Type AA cells to be installed and used to
power the evaluation kit for roaming and mobile tests.
To select the batteries as the Power Source use the correct setting for JP1.
A Low Battery status indicator is provided by D2.
