B&B Electronics

Airborne Enterprise WLNN EVB Users Guide

35

TABLE 41 - TP7 LABEL TO WLNN PIN-OUT TABLE

TP7 Designator

WLNN Pin

+3.3V

3, 4, 33, 34

VIN

CGND

GND

1, 15, 16, 36

G7

21

G6

9

G2

17

G1

19

F1

28

F7

24

F4

18

F5

12

G0

22

DTXD

6

DRXD

8

/FRESET

11

/RESET

7

NTRESET

31

TDO

10

TDI

2

TCK

20

RTCK

5

TMS

32

TX+

30

TX-

29

RX+

13

RX-

14

F0

25

F2

27

F3

26

F6

23

/RF_ACT

35
