DS2143/DS2143Q
031397 7/40
ADDRESS
A7 to A0
HEX R/W REGISTER NAME
00111011 3B R Receive Signaling
Register 12.
00111100 3C R Receive Signaling
Register 13.
00111101 3D R Receive Signaling
Register 14.
00111110 3E R Receive Signaling
Register 15.
00111111 3F R Receive Signaling
Register 16.
01000000 40 R/W Transmit Signaling
Register 1.
01000001 41 R/W Transmit Signaling
Register 2.
01000010 42 R/W Transmit Signaling
Register 3.
01000011 43 R/W Transmit Signaling
Register 4.
01000100 44 R/W Transmit Signaling
Register 5.
01000101 45 R/W Transmit Signaling
Register 6.
01000110 46 R/W Transmit Signaling
Register 7.
01000111 47 R/W Transmit Signaling
Register 8.
01001000 48 R/W Transmit Signaling
Register 9.
01001001 49 R/W Transmit Signaling
Register 10.
01001010 4A R/W Transmit Signaling
Register 11.
01001011 4B R/W Transmit Signaling
Register 12.
01001100 4C R/W Transmit Signaling
Register 13.
01001101 4D R/W Transmit Signaling
Register 14.
01001110 4E R/W Transmit Signaling
Register 15.
01001111 4F R/W Transmit Signaling
Register 16.
2.0 PARALLEL PORT
The DS2143 is controlled via a mutliplexed bidirectional
address/data bus by an external microcontroller or
microprocessor. The DS2143 can operate with either
Intel or Motorola bus timing configurations. If the BTS
pin is tied low, Intel timing will be selected; if tied high,
Motorola timing will be selected. All Motorola bus sig-
nals are listed in parenthesis (). See the timing dia-
grams in the AC Electrical Characteristics for more
details. The mutliplexed bus on the DS2143 saves pins
because the address information and data information
share the same signal paths. The addresses are pres-
ented to the pins in the first portion of the bus cycle and
data will be transferred on the pins during second por-
tion of the bus cycle. Addresses must be valid prior to
the falling edge of ALE(AS), at which time the DS2143
latches the address from the AD0 to AD7 pins. Valid
write data must be present and held stable during the
later portion of the DS or WR pulses. In a read cycle, the
DS2143 outputs a byte of data during the latter portion of
the DS or RD pulses. The read cycle is terminated and
the bus returns to a high impedance state as RD transi-
tions high in Intel timing or as DS transitions low in Moto-
rola timing.
3.0 CONTROL AND TEST REGISTERS
The operation of the DS2143 is configured via a set of
five registers. Typically, the control registers are only
accessed when the system is first powered up. Once
the DS2143 has been initialized, the control registers
will only need to be accessed when there is a change in
the system configuration. There are two Receive Con-
trol Registers (RCR1 and RCR2), two Transmit Control
Registers (TCR1 and TCR2), and a Common Control
Register (CCR). Each of the five registers are described
in this section.
The Test Register at address 15 hex is used by the fac-
tory in testing the DS2143. On power–up, the Test Reg-
ister should be set to 00 hex in order for the DS2143 to
operate properly.
