DS2143/DS2143Q

031397 21/40

9.0 CLOCK BLOCKING REGISTERS

The Receive Channel Blocking Registers
(RCBR1/RCBR2/RCBR3/RCBR4) and the Transmit
Channel Blocking Registers (TCBR1/TCBR2/TCBR3/
TCBR4) control the RCHBLK and TCHBLK pins
respectively. The RCHBLK and TCHCLK pins are user
programmable outputs that can be forced either high or

low during individual channels. These outputs can be
used to block clocks to a USART or LAPD controller in
ISDN–PRI applications. When the appropriate bits are
set to a one, the RCHBLK and TCHCLK pins will be held
high during the entire corresponding channel time. See
the timing in Section 13 for an example.

RCBR1/RCBR2/RCBR3/RCBR4: RECEIVE CHANNEL BLOCKING REGISTERS
(Address=2B to 2E Hex)

(MSB)

(LSB)

CH8

CH7

CH6

CH5

CH4

CH3

CH2

CH1

CH16

CH15

CH14

CH13

CH12

CH11

CH10

CH9

CH24

CH23

CH22

CH21

CH20

CH19

CH18

CH17

CH32

CH31

CH30

CH29

CH28

CH27

CH26

CH25

SYMBOL

POSITION

NAME AND DESCRIPTION

CH32

RCBR4.7

Receive Channel Blocking Registers.
0 = force the RCHBLK pin to remain low during this channel time

CH1

RCBR1.0

1 = force the RCHBLK pin high during this channel time

TCBR1/TCBR2/TCBR3/TCBR4: TRANSMIT CHANNEL BLOCKING REGISTERS
(Address=22 to 25 Hex)

(MSB)

(LSB)

CH8

CH7

CH6

CH5

CH4

CH3

CH2

CH1

CH16

CH15

CH14

CH13

CH12

CH11

CH10

CH9

CH24

CH23

CH22

CH21

CH20

CH19

CH18

CH17

CH32

CH31

CH30

CH29

CH28

CH27

CH26

CH25

SYMBOL

POSITION

NAME AND DESCRIPTION

CH32

TCBR4.7

Transmit Channel Blocking Registers.
0 = force the TCHBLK pin to remain low during this channel time

CH1

TCBR1.0

1 = force the TCHBLK pin high during this channel time

RCBR1 (2B)

RCBR2 (2C)

RCBR3 (2D)

RCBR4 (2E)

TCBR1 (22)

TCBR2 (23)

TCBR3 (24)

TCBR4 (25)
