DS2143/DS2143Q
031397 6/40
DS2143 REGISTER MAP
ADDRESS
A7 to A0
HEX R/W REGISTER NAME
00000000 00 R Bipolar Violation Count
Register 1.
00000001 01 R Bipolar Violation Count
Register 2.
00000010 02 R CRC4 Count Register 1.
00000011 03 R CRC4 Count Register 2.
00000100 04 R E–Bit Count Register 1.
00000101 05 R E–Bit Count Register 2.
00000110 06 R/W Status Register 1.
00000111 07 R/W Status Register 2.
00001000 08 R/W Receive Information
Register.
00011110 1E R Synchronizer Status
Register.
00010110 16 R/W Interrupt Mask
Register 1.
00010111 17 R/W Interrupt Mask
Register 2.
00010000 10 R/W Receive Control
Register 1.
00010001 11 R/W Receive Control
Register 2.
00010010 12 R/W Transmit Control
Register 1.
00010011 13 R/W Transmit Control
Register 2.
00010100 14 R/W Common Control
Register.
00010101 15 R/W Test Register.
00011000 18 W LI Control Register Byte
1.
00011001 19 W LI Control Register Byte
2.
00100000 20 R/W Transmit Align Frame
Register.
00100001 21 R/W Transmit Non–Align
Frame Register.
00101111 2F R Receive Align Frame
Register.
00011111 1F R Receive Non–Align
Frame Register.
00100010 22 R/W Transmit Channel Block-
ing Register 1.
ADDRESS
A7 to A0
HEX R/W REGISTER NAME
00100011 23 R/W Transmit Channel Block-
ing Register 2.
00100100 24 R/W Transmit Channel Block-
ing Register 3.
00100101 25 R/W Transmit Channel Block-
ing Register 4.
00100110 26 R/W Transmit Idle Register 1.
00100111 27 R/W Transmit Idle Register 2.
00101000 28 R/W Transmit Idle Register 3.
00101001 29 R/W Transmit Idle Register 4.
00101010 2A R/W Transmit Idle Definition
Register.
00101011 2B R/W Receive Channel Block-
ing Register 1.
00101100 2C R/W Receive Channel Block-
ing Register 2.
00101101 2D R/W Receive Channel Block-
ing Register 3.
00101110 2E R/W Receive Channel Block-
ing Register 4.
00110000 30 R Receive Signaling
Register 1.
00110001 31 R Receive Signaling
Register 2.
00110010 32 R Receive Signaling
Register 3.
00110011 33 R Receive Signaling
Register 4.
00110100 34 R Receive Signaling
Register 5.
00110101 35 R Receive Signaling
Register 6.
00110110 36 R Receive Signaling
Register 7.
00110111 37 R Receive Signaling
Register 8.
00111000 38 R Receive Signaling
Register 9.
00111001 39 R Receive Signaling
Register 10.
00111010 3A R Receive Signaling
Register 11.
