DS2141A
021997 14/35
RCL IMR1.1 Receive Carrier Loss.
0=interrupt masked.
1=interrupt enabled.
RLOS IMR1.0 Receive Loss of Sync.
0=interrupt masked.
1=interrupt enabled.
IMR2: INTERRUPT MASK REGISTER 2 (6Fh)
(MSB) (LSB)
RMF TMF SEC RFDL TFDL RMTCH RAF LORC
SYMBOL POSITION NAME AND DESCRIPTION
RMF IMR2.7 Receive Multiframe.
0=interrupt masked.
1=interrupt enabled.
TMF IMR2.6 Transmit Multiframe.
0=interrupt masked.
1=interrupt enabled.
SEC IMR2.5 One Second Timer.
0=interrupt masked.
1=interrupt enabled.
RFDL IMR2.4 Receive FDL Buffer Full.
0=interrupt masked.
1=interrupt enabled.
TFDL IMR2.3 Transmit FDL Buffer Empty.
0=interrupt masked.
1=interrupt enabled.
RMTCH IMR2.2 Receive FDL Match Occurrence.
0=interrupt masked.
1=interrupt enabled.
RAF IMR2.1 Receive FDL Abort.
0=interrupt masked.
1=interrupt enabled.
LORC IMR2.0 Loss of Receive Clock.
0=interrupt masked.
1=interrupt enabled.
