6
AT86RF401
1424D–RKE–09/02
XTALB 11 Crystal Output: Output from the inverting oscillator amplifier
IO3 12 Input/Output 3: General-purpose I/O and button input
IO4 13 Input/Output 4: General-purpose I/O and button input
IO5 14 Input/Output 5: General-purpose I/O and button input
DGND 15 Digital Ground
AGND 16 Analog Ground
DVDD 17 Digital Voltage Supply
Table 2. Pin Descriptions – 20-lead TSSOP (Continued)
40 pF
40 pF
10
11
V
DD
V
DD
Data
Enable
Data
Enable
12
35 k Ω
To AVR
V
DD
V
DD
Data
Enable
Data
Enable
13
35 k Ω
To AVR
V
DD
V
DD
Data
Enable
Data
Enable
14
35 k Ω
To AVR
