• Bit[5:3]: ULC[2:0]
The unlock count (ULC) bits count a certain number of reference clocks, after which the
unlock detect circuit looks for a number of cycle slips determined by CS[1:0] before
making the loc detect signal go low. The ULC bits essentially control the blackout period
of the unlock detect circuit. The unlock counter is reset by the KEY signal rising (if
ENKO is asserted), or by the LOC rising edge, or by the UPOK signal being set high.
• Bits[2:0]: LC[2:0]
The Lock Count (LC) bits control a counter that, after a number of reference clocks,
cause lock detect to go high. This counter will reset if a cycle slip or a reset signal occurs
(which happens if TXE goes low), if an out-of-lock condition occurs, if the crystal oscilla-
tor frequency is too low, or if the VCO feedback frequency is too low.
ULC[2:0]
Number of REF
Clocks of Delay
000
8
001
16
010
32
011
64
100
128
101
256
110
512
111
1024
LC[2:0]
Number of REF Clocks of Delay
000
8
001
16
010
32
011
64
100
128
101
256
110
512
111
1024
