56 VEGACOM 557 Profibus DP
Supplement A
Byte
number
in
block
Index DCS no. Index VEGAMET
509...512
VEGAMET
513...614
Index VEGAMET
509...512
VEGAMET
513...614
3...8 0xA1 DCS 161 0xA1 - MET10, DCS1 - - -
9...14 0xA2 DCS 162 0xA2 - MET10, DCS2 - - -
15...20 0xA3 DCS 163 0xA3 - MET10, DCS3 - - -
21...26 0xA4 DCS 164 0xA4 - MET10, DCS4 - - -
27...32 0xA5 DCS 165 0xA5 - MET10, DCS5 - - -
33...38 0xA6 DCS 166 0xA6 - MET10, DCS6 - - -
39...44 0xA7 DCS 167 0xA7 - MET10, DCS7 - - -
45...50 0xA8 DCS 168 - - - - - -
3...8 0xA9 DCS 169 - - - - - -
9...14 0xAA DCS 170 - - - - - -
15...20 0xAB DCS 171 - - - - - -
21...26 0xAC DCS 172 - - - - - -
27...32 0xAD DCS 173 - - - - - -
33...38 0xAE DCS 174 - - - - -
39...44 0xAF DCS 175 - - - - - -
45...50 0xB0 DCS 176 - - - - - -
3...8 0xB1 DCS 177 0xB1 - MET11, DCS1 - - -
9...14 0xB2 DCS 178 0xB2 - MET11, DCS2 - - -
15...20 0xB3 DCS 179 0xB3 - MET11, DCS3 - - -
21...26 0xB4 DCS 180 0xB4 - MET11, DCS4 - - -
27...32 0xB5 DCS 181 0xB5 - MET11, DCS5 - - -
33...38 0xB6 DCS 182 0xB6 - MET11, DCS6 - - -
39...44 0xB7 DCS 183 0xB7 - MET11, DCS7 - - -
45...50 0xB8 DCS 184 - - - - - -
3...8 0xB9 DCS 185 - - - - - -
9...14 0xBA DCS 186 - - - - - -
15...20 0xBB DCS 187 - - - - - -
21...26 0xBC DCS 188 - - - - - -
27...32 0xBD DCS 189 - - - - - -
33...38 0xBE DCS 190 - - - - - -
39...44 0xBF DCS 191 - - - - - -
45...50 0xC0 DCS 192 - - - - - -
3...8 0xC1 DCS 193 0xC1 - MET12, DCS1 - - -
9...14 0xC2 DCS 194 0xC2 - MET12, DCS2 - - -
15...20 0xC3 DCS 195 0xC3 - MET12, DCS3 - - -
21...26 0xC4 DCS 196 0xC4 - MET12, DCS4 - - -
27...32 0xC5 DCS 197 0xC5 - MET12, DCS5 - - -
33...38 0xC6 DCS 198 0xC6 - MET12, DCS6 - - -
39...44 0xC7 DCS 199 0xC7 - MET12, DCS7 - - -
45...50 0xC8 DCS 200 - - - - - -
25
Block
number
22
24
23
Sorting acc. to
VEGAMET addresses
Control command:
0xCC
Sorting acc. to
channels / DCS indices
Control command:
0xCC
21
VEGALOG
control
command:
0xCC
