VEGACOM 557 Profibus DP 45
7.3 Overview of the operating modes and control commands
In the table below, you will find all operating modes and contr ol commands which ar e available
with VEGACOM 557.
Processing Operating Control Description
system mode command
VEGAMET 50E2A 0xCC Block enquiry PC/DCS values + contact inputs/outputs
(DISBUS) (grouped acc. to VEGAMET addresses)
0xCB Block enquiry PC/DCS values + contact inputs/outputs
(grouped acc. to PC/DCS indices)
6E6A 0xCD Individual enquiry PC/DCS values
0xCE Individual enquiry contact inputs/outputs
VEGALOG 50E2A 0xCC Block enquiry PC/DCS values + contact inputs/outputs
(LOGBUS)
6E6A 0xCD Individual enquiry PC/DCS values
0xCE Individual enquiry contact inputs/outputs
Data image in VEGACOM 557
