52 VEGACOM 557 Profibus DP
Complete overview of the data image of measured values in VEGACOM
557:
Supplem. A
Supplement A
Byte
number
in
block
Index DCS no. Index VEGAMET
509...512
VEGAMET
513...614
Index VEGAMET
509...512
VEGAMET
513...614
3...8 0x01 DCS 1 - - - - - -
9...14 0x02 DCS 2 - - - 0x11 MET1, CH1 MET1, DCS1
15...20 0x03 DCS 3 - - - 0x21 MET2, CH1 MET2, DCS1
21...26 0x04 DCS 4 - - - 0x31 MET3, CH1 MET3, DCS1
27...32 0x05 DCS 5 - - - 0x41 MET4, CH1 MET4, DCS1
33...38 0x06 DCS 6 - - 0x51 MET5, CH1 MET5, DCS1
39...44 0x07 DCS 7 - - - 0x61 MET6, CH1 MET6, DCS1
45...50 0x08 DCS 8 - - - 0x71 MET7, CH1 MET7, DCS1
3...8 0x09 DCS 9 - - - 0x81 MET8, CH1 MET8, DCS1
9...14 0x0A DCS 10 - - - 0x91 MET9, CH1 MET9, DCS1
15...20 0x0B DCS 11 - - - 0xA1 MET10, CH1 MET10, DCS1
21...26 0x0C DCS 12 - - - 0xB1 MET11, CH1 MET11, DCS1
27...32 0x0D DCS 13 - - - 0xC1 MET12, CH1 MET12, DCS1
33...38 0x0E DCS 14 - - 0xD1 MET13, CH1 MET13, DCS1
39...44 0x0F DCS 15 - - - 0xE1 MET14, CH1 MET14, DCS1
45...50 0x10 DCS 16 - - - 0xF1 MET15, CH1 MET15, DCS1
3...8 0x11 DCS 17 0x11 MET1, CH1 MET1, DCS1 - - -
9...14 0x12 DCS 18 0x12 MET1, CH2 MET1, DCS2 0x12 MET1, CH2 MET1, DCS2
15...20 0x13 DCS 19 0x13 MET1, CH3 MET1, DCS3 0x22 MET2, CH2 MET2, DCS2
21...26 0x14 DCS 20 0x14 - MET1, DCS4 0x32 MET3, CH2 MET3, DCS2
27...32 0x15 DCS 21 0x15 - MET1, DCS5 0x42 MET4, CH2 MET4, DCS2
33...38 0x16 DCS 22 0x16 - MET1, DCS6 0x52 MET5, CH2 MET5, DCS2
39...44 0x17 DCS 23 0x17 - MET1, DCS7 0x62 MET6, CH2 MET6, DCS2
45...50 0x18 DCS 24 - - - 0x72 MET7, CH2 MET7, DCS2
3...8 0x19 DCS 25 - - - 0x82 MET8, CH2 MET8, DCS2
9...14 0x1A DCS 26 - - - 0x92 MET9, CH2 MET9, DCS2
15...20 0x1B DCS 27 - - - 0xA2 MET10, CH2 MET10, DCS2
21...26 0x1C DCS 28 - - - 0xB2 MET11, CH2 MET11, DCS2
27...32 0x1D DCS 29 - - - 0xC2 MET12, CH2 MET12, DCS2
33...38 0x1E DCS 30 - - - 0xD2 MET13, CH2 MET13, DCS2
39...44 0x1F DCS 31 - - - 0xE2 MET14, CH2 MET14, DCS2
45...50 0x20 DCS 32 - - - 0xF2 MET15, CH2 MET15, DCS2
3...8 0x21 DCS 33 0x21 MET2, CH1 MET2, DCS1 - - -
9...14 0x22 DCS 34 0x22 MET2, CH2 MET2, DCS2 0x13 MET1, CH3 MET1, DCS3
15...20 0x23 DCS 35 0x23 MET2, CH3 MET2, DCS3 0x23 MET2, CH3 MET2, DCS3
21...26 0x24 DCS 36 0x24 MET2, DCS4 0x33 MET3, CH3 MET3, DCS3
27...32 0x25 DCS 37 0x25 MET2, DCS5 0x43 MET4, CH3 MET4, DCS3
33...38 0x26 DCS 38 0x26 MET2, DCS6 0x53 MET5, CH3 MET5, DCS3
39...44 0x27 DCS 39 0x27 MET2, DCS7 0x63 MET6, CH3 MET6, DCS3
45...50 0x28 DCS 40 - - - 0x73 MET7, CH3 MET7, DCS3
Sorting acc. to
VEGAMET addresses
Control command:
0xCC
Sorting acc. to
channels / DCS indices
Control command:
0xCC
1
VEGALOG
control
command:
0xCC
5
Block
number
2
4
3
