VEGACOM 557 Profibus DP
39
Grouping of measured values acc. to PC/DCS output
number on LOGBUS
Block no.
PC/DCS outputs-no.
1
1...8
2
9...16
3
17...24
4
25...32
5
33...40
6
41...48
7
49...56
8
57...64
10
73...80
12
89...96
9
65...72
11
81...88
13
97...104
14
105...112
15
113...120
16
121...128
17
129...136
18
137...144
19
145...152
20
153...160
22
169...176
24
185...192
21
161...168
23
177...184
25
193...200
26
201...208
28
217...224
30
233...240
27
209...216
29
225...232
31
241...248
32
249...255
Data image in VEGACOM 557
Example:
Enquiry telegram to VEGACOM 557 (2 Byte):
0xCC 0x01
Block no. 1 is enquired
Answering telegram of VEGACOM 557 (50 Byte):
0xCC 0x00 0x01 0xYY 0x00 0x00 0xHH 0xLL 0x02 0xYY 0x00 0x00 0xHH ...
Control word
PC/DCS value-no. 1 PC/DCS value-no. 2
0xYY
= Index-Byte
0xHH
= High-Byte measured value
0xLL
= Low-Byte measured value
