Installation Guide
Power Monitoring
E51C2, E51C3
TM
E51C2 FDS E51C3 L
og
Regist
er
R/W NV Format Units Scale Range SunSpec Name Description
Apparent Energy
• • 40125
R NV ULong
VA-
hours M_Energy_VA_SF
0x0 to 0xFFFFFFFF M_Exported_VA Total Exported Apparent Energy
• • 40126
• • 40127
R NV ULong
VA-
hours M_Energy_VA_SF
0x0 to 0xFFFFFFFF M_Exported_VA_A Phase A Exported Apparent Energy
• • 40128
• • 40129
R NV ULong
VA-
hours M_Energy_VA_SF
0x0 to 0xFFFFFFFF M_Exported_VA_B Phase B Exported Apparent Energy
• • 40130
• • 40131
R NV ULong
VA-
hours M_Energy_VA_SF
0x0 to 0xFFFFFFFF M_Exported_VA_C Phase C Exported Apparent Energy
• • 40132
• • 40133
R NV ULong
VA-
hours M_Energy_VA_SF
0x0 to 0xFFFFFFFF M_Imported_VA Total Imported Apparent Energy
• • 40134
• • 40135
R NV ULong
VA-
hours M_Energy_VA_SF
0x0 to 0xFFFFFFFF M_Imported_VA_A Phase A Imported Apparent Energy
• • 40136
• • 40137
R NV ULong
VA-
hours M_Energy_VA_SF
0x0 to 0xFFFFFFFF M_Imported_VA_B Phase B Imported Apparent Energy
• • 40138
• • 40139
R NV ULong
VA-
hours M_Energy_VA_SF
0x0 to 0xFFFFFFFF M_Imported_VA_C Phase C Imported Apparent Energy
• • 40140
• • 40141
R NV UInt SF 1 M_Energy_VA_SF Real Energy Scale Factor
Reactive Energy
• • 40142
R NV ULong
VAR-
hours M_Energy_VAR_SF
0x0 to 0xFFFFFFFF M_Import_VARh_Q1 Quadrant 1: Total Imported Reactive Energy
• • 40143
• • 40144
R NV ULong
VAR-
hours M_Energy_VAR_SF
0x0 to 0xFFFFFFFF M_Import_VARh_
Q1A
Phase A - Quadrant 1: Total Imported Reactive Energy
• • 40145
• • 40146
R NV ULong
VAR-
hours M_Energy_VAR_SF
0x0 to 0xFFFFFFFF M_Import_VARh_
Q1B
Phase B - Quadrant 1: Total Imported Reactive Energy
• • 40147
• • 40148
R NV ULong
VAR-
hours M_Energy_VAR_SF
0x0 to 0xFFFFFFFF M_Import_VARh_
Q1C
Phase C - Quadrant 1: Total Imported Reactive Energy
• • 40149
• • 40150
R NV ULong
VAR-
hours M_Energy_VAR_SF
0x0 to 0xFFFFFFFF M_Import_VARh_Q2 Quadrant 2: Total Imported Reactive Energy
• • 40151
• • 40152
R NV ULong
VAR-
hours M_Energy_VAR_SF
0x0 to 0xFFFFFFFF M_Import_VARh_
Q2A
Phase A - Quadrant 2: Total Imported Reactive Energy
• • 40153
• • 40154
R NV ULong
VAR-
hours M_Energy_VAR_SF
0x0 to 0xFFFFFFFF M_Import_VARh_
Q2B
Phase B - Quadrant 2: Total Imported Reactive Energy
• • 40155
• • 40156
R NV ULong
VAR-
hours M_Energy_VAR_SF
0x0 to 0xFFFFFFFF M_Import_VARh_
Q2C
Phase C - Quadrant 2: Total Imported Reactive Energy
• • 40157
• • 40158
R NV ULong
VAR-
hours M_Energy_VAR_SF
0x0 to 0xFFFFFFFF M_Export_VARh_Q3 Quadrant 3: Total Exported Reactive Energy
• • 40159
• • 40160
R NV ULong
VAR-
hours M_Energy_VAR_SF
0x0 to 0xFFFFFFFF M_Export_VARh_
Q3A
Phase A - Quadrant 3: Total Exported Reactive Energy
• • 40161
• • 40162
R NV ULong
VAR-
hours M_Energy_VAR_SF
0x0 to 0xFFFFFFFF M_Export_VARh_
Q3B
Phase B - Quadrant 3: Total Exported Reactive Energy
• • 40163
• • 40164
R NV ULong
VAR-
hours M_Energy_VAR_SF
0x0 to 0xFFFFFFFF M_Export_VARh_
Q3C
Phase C - Quadrant 3: Total Exported Reactive Energy
• • 40165
• • 40166
R NV ULong
VAR-
hours M_Energy_VAR_SF
0x0 to 0xFFFFFFFF M_Export_VARh_Q4 Quadrant 4: Total Exported Reactive Energy
• • 40167
SunSpec Register Blocks (cont.)
