Installation Guide
Power Monitoring
E51C2, E51C3
TM
Modbus Point Map
E51C2 FDS E51C3 L
og
Regist
er
R/W NV Format Units Scale Range Description
Integer Data: Summary of Active Phases
• • 001
R NV SLong kWh E
-2147483647 to
+2147483647 Real Energy: Net (Import - Export)
MSR
Accumulated
Real Energy
(Ph)
Clear via reset
register 129
• • 002 LSR
• • 003
R NV ULong kWh E 0 to 0xFFFFFFFF
Real Energy: Quadrants 1 & 4
Import MSR
• • 004 LSR
• • 005
R NV ULong kWh E 0 to 0xFFFFFFFF
Real Energy: Quadrants 2 & 3
Export MSR
• • 006 LSR
• • 007
R NV ULong kVARh E 0 to 0xFFFFFFFF
Reactive Energy - Quadrant 1:
Lags Import Real Energy (IEC) Inductive (IEEE) MSR
Accumulated
Reactive Energy
(Qh):
Quadrants 1 + 2
= Import
Quadrants 3 + 4
= Export
• • 008 LSR
• • 009
R NV ULong kVARh E 0 to 0xFFFFFFFF
Reactive Energy - Quadrant 2:
Leads Export Real Energy (IEC) Inductive (IEEE)
MSR
• • 010 LSR
• • 011
R NV ULong kVARh E 0 to 0xFFFFFFFF
Reactive Energy - Quadrant 3:
Lags Export Real Energy (IEC) Capacitive (IEEE)
MSR
• • 012 LSR
• • 013
R NV ULong kVARh E 0 to 0xFFFFFFFF
Reactive Energy - Quadrant 4:
Leads Import Real Energy (IEC) Capacitive (IEEE) MSR
• • 014 LSR
• • 015
R NV SLong kVAh E
-2147483647 to
+2147483647 Apparent Energy: Net (Import - Export)
MSR
Accumulated
Apparent
Energy (Sh):
Import and
Export
correspond
with Real
Energy
• • 016 LSR
• • 017
R NV ULong kVAh E 0 to 0xFFFFFFFF
Apparent: Quadrants 1 & 4
Import MSR
• • 018 LSR
• • 019
R NV ULong kVAh E 0 to 0xFFFFFFFF
Apparent: Quadrants 2 & 3
Export MSR
• • 020 LSR
• • 021 R SInt kW W -32767 to +32767 Total Instantaneous Real (P) Power
• • 022 R SInt kVAR W 0 to 32767 Total Instantaneous Reactive (Q) Power
• • 023 R UInt kVA W 0 to 32767 Total Instantaneous Apparent (S) Power (vector sum)
• • 024 R SInt Ratio 0.0001 -10000 to +10000 Total Power Factor (total kW / total kVA)
• • 025 R UInt Volt V 0 to 32767 Voltage, L-L (U), average of active phases
• • 026 R UInt Volt V 0 to 32767 Voltage, L-N (V), average of active phases
• • 027 R UInt Amp I 0 to 32767 Current, average of active phases
• • 028 UInt Hz 0.01 4500 to 6500 Frequency
• • 029 R SInt kW W -32767 to +32767 Total Real Power Present Demand
• • 030 SInt kVAR W -32767 to +32767 Total Reactive Power Present Demand
• • 031 R SInt kVA W -32767 to +32767 Total Apparent Power Present Demand
• • 032 R NV SInt kW W -32767 to +32767 Total Real Power Max. Demand
Import
Reset via register
129
• • 033 R NV SInt kVAR W -32767 to +32767 Total Reactive Power Max. Demand
• • 034 R NV SInt kVA W -32767 to +32767 Total Apparent Power Max. Demand
• • 035 R NV SInt kW W -32767 to +32767 Total Real Power Max. Demand
Export • • 036 R NV SInt kVAR W -32767 to +32767 Total Reactive Power Max. Demand
• • 037 R NV SInt kVA W -32767 to +32767 Total Apparent Power Max. Demand
• • 038 R UInt Reserved, returns 0x8000 (QNAN)
• • 039
R NV ULong 0 to 0xFFFFFFFF
Pulse Counter 1
(Import Real Energy) MSR
Contact Closure Counters. Valid for both pulse
inputs and outputs. E51Cx counts are shown in
(). See register 144 - Energy Per Pulse for the
Wh per pulse count.
• • 040 LSR
• • 041
R NV ULong 0 to 0xFFFFFFFF
Pulse Counter 2
(Export Real Energy) MSR
• • 042 LSR
