Installation Guide
Power Monitoring
E51C2, E51C3
TM
E51C2 FDS E51C3 L
og
Regist
er
R/W NV Format Units Scale Range Description
Integer Data: Per Phase
• • 043
R NV ULong kWh E 0 to 0xFFFFFFFF
Accumulated Real Energy,
Phase A
MSR
Import
Accumulated Real
Energy (Ph), per
phase
• • 044 LSR
• • 045
R NV ULong kWh E 0 to 0xFFFFFFFF
Accumulated Real Energy,
Phase B
MSR
• • 046 LSR
• • 047
R NV ULong kWh E 0 to 0xFFFFFFFF
Accumulated Real Energy,
Phase C
MSR
• • 048 LSR
• • 049
R NV ULong kWh E 0 to 0xFFFFFFFF
Accumulated Real Energy,
Phase A
MSR
Export
• • 050 LSR
• • 051
R NV ULong kWh E 0 to 0xFFFFFFFF
Accumulated Real Energy,
Phase B
MSR
• • 052 LSR
• • 053
R NV ULong kWh E 0 to 0xFFFFFFFF
Accumulated Real Energy,
Phase C
MSR
• • 054 LSR
• • 055
R NV ULong kVARh E 0 to 0xFFFFFFFF
Accumulated Q1 Reactive
Energy, Phase A
MSR
Import
Accumulated
Reactive Energy
(Qh), Per Phase
• • 056 LSR
• • 057
R NV ULong kVARh E 0 to 0xFFFFFFFF
Accumulated Q1 Reactive
Energy, Phase B
MSR
• • 058 LSR
• • 059
R NV ULong kVARh E 0 to 0xFFFFFFFF
Accumulated Q1 Reactive
Energy, Phase C
MSR
• • 060 LSR
• • 061
R NV ULong kVARh E 0 to 0xFFFFFFFF
Accumulated Q2 Reactive
Energy, Phase A
MSR
• • 062 LSR
• • 063
R NV ULong kVARh E 0 to 0xFFFFFFFF
Accumulated Q2 Reactive
Energy, Phase B
MSR
• • 064 LSR
• • 065
R NV ULong kVARh E 0 to 0xFFFFFFFF
Accumulated Q2 Reactive
Energy, Phase C
MSR
• • 066 LSR
• • 067
R NV ULong kVARh E 0 to 0xFFFFFFFF
Accumulated Q3 Reactive
Energy, Phase A
MSR
Export
• • 068 LSR
• • 069
R NV ULong kVARh E 0 to 0xFFFFFFFF
Accumulated Q3 Reactive
Energy, Phase B
MSR
• • 070 LSR
• • 071
R NV ULong kVARh E 0 to 0xFFFFFFFF
Accumulated Q3 Reactive
Energy, Phase C
MSR
• • 072 LSR
• • 073
R NV ULong kVARh E 0 to 0xFFFFFFFF
Accumulated Q4 Reactive
Energy, Phase A
MSR
• • 074 LSR
• • 075
R NV ULong kVARh E 0 to 0xFFFFFFFF
Accumulated Q4 Reactive
Energy, Phase B
MSR
• • 076 LSR
• • 077
R NV ULong kVARh E 0 to 0xFFFFFFFF
Accumulated Q4 Reactive
Energy, Phase C
MSR
• • 078 LSR
Modbus Point Map (cont.)
