Sunspec register blocks (cont.) – Veris Industries E51C3 Install User Manual
Page 31
ZL0067-0C
Page 31 of 34
©2013 Veris Industries USA 800.354.8556 or +1.503.598.4564 / [email protected] 06131
Alta Labs, Enercept, Enspector, Hawkeye, Trustat, Aerospond, Veris, and the Veris ‘V’ logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
Other companies’ trademarks are hereby acknowledged to belong to their respective owners.
Installation Guide
Power Monitoring
E51C2, E51C3
TM
E51C2 FDS
E51C3 L
og
Regist
er
R/W NV Format Units
Scale
Range
SunSpec Name
Description
Power
Real Power
• • 40088
R
SInt
Watts M_AC_Power_SF
-32767 to +32767 M_AC_Power
Total Real Power (sum of active phases)
• • 40089
R
SInt
Watts M_AC_Power_SF
-32767 to +32767 M_AC_Power_A
Phase A AC Real Power
• • 40090
R
SInt
Watts M_AC_Power_SF
-32767 to +32767 M_AC_Power_B
Phase B AC Real Power
• • 40091
R
SInt
Watts M_AC_Power_SF
-32767 to +32767 M_AC_Power_C
Phase A AC Real Power
• • 40092
R
NV SInt
SF
1
M_AC_Power_SF
AC Real Power Scale Factor
Apparent Power
• • 40093
R
SInt
Volt-
Amps M_AC_VA_SF
-32767 to +32767 M_AC_VA
Total AC Apparent Power (sum of active phases)
• • 40094
R
SInt
Volt-
Amps M_AC_VA_SF
-32767 to +32767 M_AC_VA_A
Phase A AC Apparent Power
• • 40095
R
SInt
Volt-
Amps M_AC_VA_SF
-32767 to +32767 M_AC_VA_B
Phase B AC Apparent Power
• • 40096
R
SInt
Volt-
Amps M_AC_VA_SF
-32767 to +32767 M_AC_VA_C
Phase A AC Apparent Power
• • 40097
R
NV SInt
SF
1
M_AC_VA_SF
AC Apparent Power Scale Factor
Reactive Power
• • 40098
R
SInt
VAR
M_AC_VAR_SF
-32767 to +32767 M_AC_VAR
Total AC Reactive Power (sum of active phases)
• • 40099
R
SInt
VAR
M_AC_VAR_SF
-32767 to +32767 M_AC_VAR_A
Phase A AC Reactive Power
• • 40100
R
SInt
VAR
M_AC_VAR_SF
-32767 to +32767 M_AC_VAR_B
Phase B AC Reactive Power
• • 40101
R
SInt
VAR
M_AC_VAR_SF
-32767 to +32767 M_AC_VAR_C
Phase A AC Reactive Power
• • 40102
R
NV SInt
SF
1
M_AC_VAR_SF
AC Reactive Power Scale Factor
Power Factor
• • 40103
R
SInt
%
M_AC_PF_SF
-32767 to +32767 M_AC_PF
Average Power Factor (average of active phases)
• • 40104
R
SInt
%
M_AC_PF_SF
-32767 to +32767 M_AC_PF_A
Phase A Power Factor
• • 40105
R
SInt
%
M_AC_PF_SF
-32767 to +32767 M_AC_PF_B
Phase B Power Factor
• • 40106
R
SInt
%
M_AC_PF_SF
-32767 to +32767 M_AC_PF_C
Phase A Power Factor
• • 40107
R
NV SInt
SF
1
M_AC_PF_SF
AC Power Factor Scale Factor
Accumulated Energy
Real Energy
• • 40108
R
NV ULong
Watt-
hours M_Energy_W_SF
0x0 to 0xFFFFFFFF M_Exported_W
Total Exported Real Energy
• • 40109
• • 40110
R
NV ULong
Watt-
hours M_Energy_W_SF
0x0 to 0xFFFFFFFF M_Exported_W_A Phase A Exported Real Energy
• • 40111
• • 40112
R
NV ULong
Watt-
hours M_Energy_W_SF
0x0 to 0xFFFFFFFF M_Exported_W_B Phase B Exported Real Energy
• • 40113
• • 40114
R
NV ULong
Watt-
hours M_Energy_W_SF
0x0 to 0xFFFFFFFF M_Exported_W_C Phase C Exported Real Energy
• • 40115
• • 40116
R
NV ULong
Watt-
hours M_Energy_W_SF
0x0 to 0xFFFFFFFF M_Imported_W
Total Imported Real Energy
• • 40117
• • 40118
R
NV ULong
Watt-
hours M_Energy_W_SF
0x0 to 0xFFFFFFFF M_Imported_W_A Phase A Imported Real Energy
• • 40119
• • 40120
R
NV ULong
Watt-
hours M_Energy_W_SF
0x0 to 0xFFFFFFFF M_Imported_W_B Phase B Imported Real Energy
• • 40121
• • 40122
R
NV ULong
Watt-
hours M_Energy_W_SF
0x0 to 0xFFFFFFFF M_Imported_W_C Phase C Imported Real Energy
• • 40123
• • 40124
R
NV SF
SF
1
M_Energy_W_SF
Real Energy Scale Factor
SunSpec Register Blocks (cont.)
