Installation Guide
Power Monitoring
E51C2, E51C3
TM
This section describes the Modbus registers reserved for SunSpec compliance-related information. See www.sunspec.org for
the original specifications. SunSpec Register Blocks
E51C2 FDS E51C3 L
og
Regist
er
R/W NV Format Units Scale Range SunSpec Name Description
SunSpec 1.0 Common Model
• • 40001
R NV ULong
0x5375
6e53
C_SunSpec_ID
ASCII “SunS”. Identifies this as the beginning of a SunSpec Modbus
point • • 40002
• • 40003
R NV UInt 1 C_SunSpec_DID SunSpec common model Device ID
• • 40004 R NV UInt 65 C_SunSpec_Length Length of the common model block
• • 40005 to 40020 R NV String (32) ASCII C_Manufacturer null terminated ASCII text string = “VERIS”
• • 40021 to 40036 R NV String (32) ASCII C_Model null terminated ASCII text string = “E51C_”
• • 40037 to 40044 R NV String (16) ASCII C_Options null terminated ASCII text string
• • 40045 to 40052 R NV String (16) ASCII C_Version null terminated ASCII text string
• • 40053 to 40068 R NV String (32) ASCII C_SerialNumber null terminated ASCII text string
• • 40068 R NV UInt ASCII C_SunSpec_Length Modbus address
SunSpec 1.1 Integer Meter Model
Identification
• • 40070 R NV UInt 201 to 204 C_SunSpec_DID
SunSpec Integer meter model device IDs. Meter configuration by
device ID:
201 = single phase (A-N or A-B) meter
202 = split single phase (A-B-N) meter
203 = Wye-connect 3-phase (ABCN) meter
204 = delta-connect 3-phase (ABC) meter
• • 40071 R NV UInt 105 C_SunSpec_Length Length of the meter model block
Current
• • 40072 R SInt Amps M_AC_Current_SF -32767 to +32767 M_AC_Current AC Current (sum of active phases)
• • 40073 R SInt Amps M_AC_Current_SF -32767 to +32767 M_AC_Current_A Phase A AC current
• • 40074 R SInt Amps M_AC_Current_SF -32767 to +32767 M_AC_Current_B Phase B AC current
• • 40075 R SInt Amps M_AC_Current_SF -32767 to +32767 M_AC_Current_C Phase C AC current
• • 40076 R NV SInt 1 M_AC_Current_CN AC Current Scale Factor
Voltage: Line to Neutral
• • 40077 R SInt Volts M_AC_Voltage_SF -32767 to +32767 M_AC_Voltage_LN Line to Neutral AC voltage (average of active phases)
• • 40078 R SInt Volts M_AC_Voltage_SF -32767 to +32767 M_AC_Voltage_AN Phase A to Neutral AC Voltage
• • 40079 R SInt Volts M_AC_Voltage_SF -32767 to +32767 M_AC_Voltage_BN Phase B to Neutral AC Voltage
• • 40080 R SInt Volts M_AC_Voltage_SF -32767 to +32767 M_AC_Voltage_CN Phase C to Neutral AC Voltage
Voltage: Line to Line
• • 40081 R SInt Volts M_AC_Voltage_SF -32767 to +32767 M_AC_Voltage_LL Line to Line AC voltage (average of active phases)
• • 40082 R SInt Volts M_AC_Voltage_SF -32767 to +32767 M_AC_Voltage_AB Phase A to Phase B AC Voltage
• • 40083 R SInt Volts M_AC_Voltage_SF -32767 to +32767 M_AC_Voltage_BC Phase B to Phase C AC Voltage
• • 40084 R SInt Volts M_AC_Voltage_SF -32767 to +32767 M_AC_Voltage_CA Phase C to Phase A AC Voltage
• • 40085 R NV SInt 1 M_AC_Voltage_SF AC Voltage Scale Factor
Frequency
• • 40086 R SInt Hertz M_AC_Freq_SF -32767 to +32767 M_AC_Freq AC Frequency
• • 40087 R NV SInt SF 1 M_AC_Freq_SF AC Frequency Scale Factor
