16 Gas sampling and gas conditioning technology 4-1.2-ME
The mounting of the sample gas hoses and the condensate hoses is to be executed as follows:

Remove the union nut from the sealing ring couplings by turning it anti-clockwise. The nut should
be removed from the thread with great care so as to ensure that the loose sealing ring in the nut is
not lost.

Place the union nut over the connecting hose.

Push the sealing ring over the connecting hose with the thicker bead towards the nut.

Place the hose over the nipple on the thread.
N O T E !
The tightness of the connections can only be guaranteed if the connecting
hose has a straight edge (use a hose cutter).

The union nut is to be screwed tight by hand.
The hose will no longer be able to slip off, and is now compression-proof.
The hoses are to be removed in the reverse order.
W A R N I N G !
Aggressive condensate is possible.
Wear protective glasses and proper protective clothing!
12.2
DISPLACE THE CONNECTIONS TO THE BACK OF THE HOUSING
If the installation conditions necessitate to displace the connections to the back of the housing, this is
possible very easily:

Remove connection sheet fixing screws (see Fig.4)

Remove cover angle fixing srews at the back of the unit

Install connection sheet with 2 fixing screws at the back of the unit

Install cover angle with 2 fixing screws at the top of the housing
12.3
ELECTRICAL CONNECTIONS
W A R N I N G !
False supply voltage can damage the equipment. When connecting
the equipment, please ensure that the supply voltage is identical
with the information provided on the model type plate!
