Steps 5 and 6 may be done later on, provided that you first open the layout with the
Layout > Open option.
How to Save a Layout with a New Name
Once you have opened and arranged some windows in the way you want them to appear,
you can save the current layout with a new name. To do so, proceed as follows:
1. Select Save current layout as in the Layout menu.
The Save Current Layout As window appears:
2. Enter the appropriate information and click OK.
The new Layout name is displayed in the Status bar of the Main window.
Possible Operations on Layouts
Clicking the Layout option from the Layout menu on the Menu bar displays the following
commands.
Column 1 Column 2
New Opens the New Layout window to create a layout. See
section "How to Define Layout" on page 50.
Open Opens the Load Layout window from which you can select
an existing layout. The IPDirector windows associated to
the selected layout will then open on screen.
Save Layout Saves the layout of the open windows with the name of the
currently loaded layout, which is displayed in the Status bar
of the Main window. See section "How to Define Layout" on
page 50.
