Configuration
eud-1431/1.0 – OIP R8.3 – 02.2012
85
Display
You can modify the following ring display settings of your phone:
Configurable keys/Expansion key module
You want to store a number or function under an available Configurable key , Foxkey , or
Softkey of your phone.
The available configurable keys depend on your phone. You can obtain more details
from your system administrator or in the User’s Guide for your phone.
You can assign each key with a specific Action type so you can trigger a particular
action by simply pressing that key. Choice available:
• Number key: On each Foxkey you can store one number and name, and on each
configurable key you can store two call numbers and the associated names.
• Function key: Activate/deactivate function. Usually the function is assigned so
that you activate the function with the first keystroke, and deactivate the com-
mand again with a second keystroke.
• Team key: Organisation within the team. For more information on this refer to your
phone's User Guide.
Setting Description
Backlight Duration of backlight ( Off , On , 10 min. , 1 day ).
Backlight intensity Dark to light backlight.
Contrast Contrast between backlight and font.
Idle display Display picture in idle state.
Open the Configuration .
Select the Phone dialog box. If you have registered several phones, highlight
the phone you want.
Select the
Display tab.
Select the settings you want and click Apply to confirm.
➔
The settings are stored.
Open the Configuration .
Select the Phone dialog box. If you have registered several phones, highlight
the phone you want.
Select the
Configurable keys or Expansion key module tab.
