Prestige P645 ADSL Internet Access Router
5-4 Remote Node TCP/IP Configuration
Figure 5-4 Sample IP Addresses for a TCPI/IP LAN-to-LAN Connection
To configure the TCP/IP parameters of a remote node, first configure the fields in Menu 11.1 – Remote
Node Profile, as shown in the next table. For more details on the IP Option fields, refer to the section on
Internet access.
Figure 5-5 Menu 11.1 Remote Node Profile
Menu 11.1 - Remote Node Profile
Rem Node Name= ChangeMe
Active= Yes
Encapsulation= PPP
Multiplexing= VC-based
Incoming:
Rem Login=
Rem Password=********
Outgoing:
My Login= oscar
My Password= ********
Authen= CHAP/PAP
Route= IP
Bridge= No
Edit PPP Options= No
Rem IP Addr= 0.0.0.0
Edit IP/IPX/Bridge= No
Session Options:
Edit Filter Sets= No
PPPoE Idle Timeout (sec)= N/A
PPPoE Service Name= N/A
Schedule Sets= N/A
Press ENTER to CONFIRM or ESC to CANCEL:
