Prestige 645 ADSL Internet Access Router
IP Policy Routing 12-3
To setup a routing policy, perform the following procedures:
Step 1. Type 25 in the main menu to open Menu 25 – IP Routing Policy Setup.
Step 2. Type the index of the policy set you want to configure to open Menu 25.1 – IP Routing Policy
Setup.
Menu 25.1 shows the summary of a policy set, including the criteria and the action of a single policy, and
whether a policy is active or not. Each policy contains two lines. The former part is the criteria of the
incoming packet and the latter is the action. Between these two parts, separator “|” means the action is taken
on criteria matched and separator “=” means the action is taken on criteria not matched.
Figure 12-2 Menu 25.1 – Sample IP Routing Policy Setup
Table 12-1 IP Routing Policy Setup
ABBREVIATION MEANING
Criterion SA Source IP Address
SP Source Port
DA Destination IP Address
Menu 25.1 - IP Routing Policy Setup
# A Criteria/Action
- - --------------------------------------------------------------------------
1 Y SA=1.1.1.1-1.1.1.1,DA=2.2.2.2-2.2.2.5
SP=20-25,DP=20-25,P=6,T=NM,PR=0 |GW=192.168.1.1,T=MT,PR=0
2 N __________________________________________________________________________
__________________________________________________________________________
3 N __________________________________________________________________________
__________________________________________________________________________
4 N __________________________________________________________________________
__________________________________________________________________________
5 N __________________________________________________________________________
__________________________________________________________________________
6 N __________________________________________________________________________
__________________________________________________________________________
Enter Policy Rule Number (1-6) to Configure:
