Prestige 645 ADSL Internet Access Router
10-2 System Maintenance
Please note that displaying this screen degrades system performance.
Figure 10-2 Menu 24.1 - System Maintenance – Status
The following table describes the fields present in Menu 24.1 - System Maintenance - Status.
Table 10-1 System Maintenance - Status Menu Fields
FIELD DESCRIPTION
This is the remote node index number and link type. Link types are: Node-Lnk
PPP, ENET, 1483 and PPPoE.
Status Shows the status of the remote node.
TxPkts The number of packets transmitted to this remote node.
RxPkts The number of packets received from this remote node.
Errors The number of error packets on this connection.
Tx B/s Shows the transmission rate in bytes per second.
Rx B/s Shows the receiving rate in bytes per second.
Up Time Time this channel has been connected to the remote node.
Ethernet
Status Shows the current status of the LAN.
Menu 24.1 - System Maintenance – Status
Node-Lnk
1-1483
2
3
4
5
6
7
8
Status
Up
N/A
N/A
N/A
N/A
N/A
N/A
N/A
TxPkts
1462
0
0
0
0
0
0
0
RxPkts
1567
0
0
0
0
0
0
0
Errors
0
0
0
0
0
0
0
0
Tx B/s
222
0
0
0
0
0
0
0
Rx B/s
211
0
0
0
0
0
0
0
Up Time
2:15:16
0:00:00
0:00:00
0:00:00
0:00:00
0:00:00
0:00:00
0:00:00
Ethernet:
Status: 10M/Full Duplex
Collisions: 0
Tx Pkts: 1583
Rx Pkts: 1521
WAN:
Line Status: Up
Upstream Speed: 608 kbps
Downstream Speed: 4000 kbps
CPU Load = 4.25%
Press Command:
COMMANDS: 1-Reset Counters ESC-Exit
