Prestige 645 ADSL Internet Access Router
8-24 Filter Configuration
filter set(s) that you want to apply as appropriate. You can choose up to four filter sets (from twelve) by
entering their numbers separated by commas, for example, 2, 4, 7, 9. The Prestige does not have any of the
default filters applied to the Ethernet port when it is shipped.
Figure 8-17 Filtering Ethernet traffic
8.6.2 Remote Node Filters
Go to Menu 11.5 (shown below – note that call filter sets are only present for PPPoE encapsulation) and
enter the number(s) of the filter set(s) as appropriate. You can cascade up to four filter sets by entering their
numbers separated by commas. The factory default filter set, NetBIOS_WAN, can be applied in Menu 11.5
to block local NetBIOS traffic from triggering calls to the ISP (when you are using PPPoE encapsulation
only). Enter “1” in the protocol filters field under Call Filter Sets when using PPPoE encapsulation and in
protocol filters under Output Filter Sets – protocol filters when using Ethernet encapsulation. The
factory default filter set “6”, FTP_TELNET_WEB, is inserted in the protocol filters field under Input
Filter Sets in menu 11.5 to block FTP, Telnet, HTTP and TFTP traffic from coming into the WAN port.
Filter set “4”, PPPoE, blocks PPP connections from the WAN Port. Apply them as shown in the following
figure.
Menu 3.1 - General Ethernet Setup
Input Filter Sets:
protocol filters=
device filters=
Output Filter Sets:
protocol filters=
device filters=
Press ENTER to Confirm or ESC to Cancel:
