Prestige 645 ADSL Internet Access Router
Filter Configuration 8-11
•
Abbreviations Used If Filter Type Is IPX
Table 8-3 Abbreviations Used If Filter Type Is IPX
ABBREVIATION DESCRIPTION
PT IPX Packet Type
SS Source Socket
DS Destination Socket
If the filter type is GEN (generic), the abbreviations listed in the following table will be used.
Table 8-4 Abbreviations Used If Filter Type Is GEN
ABBREVIATION DESCRIPTION
Off Offset
Len Length
Refer to the next section for information on configuring the filter rules.
8.3 Configuring a Filter Rule
To configure a filter rule, enter its number in Menu 21.1 - Filter Rules Summary and press [ENTER] to
open menu 21.1.1 for the rule.
There are three types of filter rules: TCP/IP, IPX and Generic. Depending on the type of rule, the
parameters below the type will be different. Use the [SPACE BAR] to select the type of rule that you wish
to create in the Filter Type field and press [ENTER] to open the respective menu.
To speed up filtering, all rules in a filter set must be of the same class, i.e., protocol filters or generic filters.
The class of a filter set is determined by the first rule that you create. When applying the filter sets to a
port, separate menu fields are provided for protocol and device filter sets. If you include a protocol filter set
in a device filters field or vice versa, the Prestige will warn you and will not allow you to save.
