Prestige 645 ADSL Internet Access Router
Internet Access 3-13
Figure 3-7 Internet Access Setup
Table 3-5 Internet Access Setup Menu Fields
FIELD DESCRIPTION EXAMPLE
ISP’s Name Enter the name of your Internet Service Provider, e.g.,
MyISP. This information is for identification purposes only. MyISP
Encapsulation Press the [SPACE BAR] to select the method of
encapsulation used by your ISP. The choices are PPP,
RFC 1483, PPPoE or ENET ENCAP. Please see section
3.9 for related information. PPP
Multiplexing Press the [SPACE BAR] to select the method of
multiplexing used by your ISP - either VC-based or LLC-
based. VC-based
VPI # Enter the Virtual Path Identifier (VPI) that the telephone
company gives you. 10
VCI # Enter the Virtual Channel Identifier (VCI) that the telephone
company gives you. 10
Service Name Only available when PPPoE encapsulation is used. Enter
the name of your PPPoE service provider. This is the same
as PPPoE Service Name in menu 11.1.
My Login Enter the login name that your ISP gives you. tarbuck
My Password Enter the password associated with the login name above. ***
Single User Account Press the [SPACE BAR] to enable or disable SUA. Please
see the following section for a more detailed discussion on No
Menu 4 - Internet Access Setup
ISP's Name= ChangeMe
Encapsulation= PPPoE
Multiplexing= LLC-based
VPI #= 10
VCI #= 10
Service Name=
y My Login= tarbuck
My Password= *********
Single User Account= Yes
J IP Address Assignment= Static
IP Address= 0.0.0.0
ENET ENCAP Gateway= 0.0.0.0
Press ENTER to confirm or ESC to cancel:
Get the VPI and
VCI from your
telephone
company and the
other
information from
your ISP.
