Prestige 645 ADSL Internet Access Router
13-4 Call Scheduling
13.4 Applying Schedule Sets to Remote Nodes
Once your schedule sets are configured, you must apply them to the desired remote node(s). Enter menu 11
from the main menu and enter a node number to edit. In menu 11.1 press the [SPACE BAR] to select
PPPoE in the Encapsulation field. You can apply up to four schedule sets, separated by commas, for one
remote node. Enter the schedule set numbers in the Schedule Sets field. In the following example schedule
sets 2, 5, 7 and 9 are applied.
Figure 13-3 Applying Schedule Sets to a Remote Node Example (PPPoE Encapsulation)
Menu 11.1 - Remote Node Profile
Rem Node Name= ChangeMe
Active= Yes
Encapsulation= PPPoE
Multiplexing= VC-based
Incoming:
Rem Login=
Rem Password=********
Outgoing:
My Login= oscar
My Password= ********
Authen= CHAP/PAP
Route= IP
Bridge= No
Edit PPP Options= No
Rem IP Addr= 0.0.0.0
Edit IP/IPX/Bridge= No
Session Options:
Edit Filter Sets= No
PPPoE Idle Timeout (sec)= N/A
PPPoE Service Name= N/A
Schedule Sets= 2,5,7,9
Press ENTER to CONFIRM or ESC to CANCEL:
