Prestige P645 ADSL Internet Access Router
5-2 Remote Node TCP/IP Configuration
In menu 11.1, move the cursor to the Edit IP/IPX/Bridge, then press the [SPACE BAR] to select Yes.
Press [ENTER]
to open Menu 11.3 - Network Layer Options.
There are two versions of menu 11.3 for the Prestige, depending on whether you chose VC-based or LLC-
based multiplexing in menu 11.1.
VC-Based Multiplexing
Remember that for VC-based multiplexing, by prior mutual agreement, a protocol is assigned a specific
virtual circuit, e.g., VC1 will carry IP, VC2 will carry IPX etc.
Figure 5-2 Menu 11.3 for VC-based multiplexing with RFC 1483 and ENET ENCAP
In this case, separate VPI and VCI numbers must be specified for each protocol.
LLC-based multiplexing
For LLC-based multiplexing, one VC carries multiple protocols with protocol identifying information
being contained in each packet header.
Menu 11.3 - Remote Node Network Layer Options
IP Options:
Rem IP Addr: 0.0.0.0
Rem Subnet Mask= 0.0.0.0
IP Address Assignment = Dynamic
My WAN Addr= 0.0.0.0
Single User Account= No
Metric= 2
Private= No
RIP Direction= Both
Version= RIP-2B
Multicast= None
IP Policies=
VPI #= 0
VCI #= 35 Enter here to Confirm IPX Options :
Rem LAN Net #= N/A
My WAN Net #= N/A
Hop Count= N/A
Tick Count= N/A
W/D Spoofing(min)= N/A
SAP/RIP Timeout(min)=N/A
Dial-On-Query= N/A
VPI #= N/A
VCI #= N/A
Bridge Options:
Dial-On-Broadcast= N/A
Ethernet Addr Timeout(min)= N/A
VPI #= N/A
VCI #= N/A
Or ESC to Cancel:
Press Space Bar to Toggle.
