Prestige 650 Series User’s Guide
Wizard Setup 3-15
Table 3-6 Wizard : LAN Configuration
LABEL DESCRIPTION
Client IP Pool Starting
Address
This field specifies the first of the contiguous addresses in the IP address pool.
Size of Client IP Pool This field specifies the size or count of the IP address pool.
Primary DNS Server Enter the IP addresses of the DNS servers. The DNS servers are passed to the
DHCP clients along with the IP address and the subnet mask.
Secondary DNS Server As above.
Back Click Back to go back to the previous screen.
Finish Click Finish to save the settings and proceed to the next wizard screen.
3.13 Wizard Setup Configuration: Connection Tests
The Prestige automatically tests the connection to the computer(s) connected to the LAN ports. To test the
connection from the Prestige to the ISP, click Start Diagnose. Otherwise click Return to Main Menu to go
back to the Site Map screen.
Figure 3-8 Wizard Screen 4
