Prestige 650 Series User’s Guide
Maintenance 21-9
The following table describes the labels in this screen.
Table 21-5 Channel Usage Table
LABEL DESCRIPTION
Channel This is the index number of the channel.
IP Address This field displays Yes if another AP or Ad-hoc network is using the channel within the
Prestige’s transmission range.
Back Click Back to go to the main Wireless LAN screen.
Refresh Click Refresh to renew the information in the table.
21.5 Diagnostic Screens
These read-only screens display information to help you identify problems with the Prestige.
Click Diagnostic to display the following screen.
Figure 21-6 Diagnostic
21.5.1 Diagnostic General Screen
Click Diagnostic and then General to open the screen shown next.
