Prestige 650 Series User’s Guide

Remote Node Configuration

27-1

Chapter 27

Remote Node Configuration

This chapter covers remote node configuration.

27.1 Remote Node Setup Overview

This section describes the protocol-independent parameters for a remote node. A remote node is required
for placing calls to a remote gateway. A remote node represents both the remote gateway and the network
behind it across a WAN connection. When you use menu 4 to set up Internet access, you are configuring
one of the remote nodes.

You first choose a remote node in Menu 11- Remote Node Setup. You can then edit that node’s profile in
menu 11.1, as well as configure specific settings in three submenus: edit IP and bridge options in menu
11.3; edit ATM options in menu 11.6; and edit filter sets in menu 11.5.

27.2 Remote Node Setup

This section describes the protocol-independent parameters for a remote node.

27.2.1 Remote Node Profile

To configure a remote node, follow these steps:

Step 1. From the main menu, enter 11 to display Menu 11 - Remote Node Setup.

Step 2. When menu 11 appears, as shown in the following figure, type the number of the remote node

that you want to configure.
