Prestige 650 Series User’s Guide

26-4

Internet

Access

Table 26-1 Menu 3.2.1 IP Alias Setup

FIELD DESCRIPTION

EXAMPLE

IP Alias

Choose Yes to configure the LAN network for the Prestige.

Yes

IP Address

Enter the IP address of your Prestige in dotted decimal notation

192.168.1.1

IP Subnet
Mask

Your Prestige will automatically calculate the subnet mask based on
the IP address that you assign. Unless you are implementing
subnetting, use the subnet mask computed by the Prestige

255.255.255.0

RIP Direction

Press [

SPACE BAR

] to select the RIP direction. Choices are None,

Both, In Only or Out Only.

None

Version

Press [

SPACE BAR]

to select the RIP version. Choices are RIP-1,

RIP-2B or RIP-2M.

RIP-1

Incoming
Protocol Filters

Enter the filter set(s) you wish to apply to the incoming traffic between
this node and the Prestige.

Outgoing
Protocol Filters

Enter the filter set(s) you wish to apply to the outgoing traffic between
this node and the Prestige.

When you have completed this menu, press [

ENTER

] at the prompt “Press ENTER to Confirm…” to save

your configuration, or press [

ESC

] at any time to cancel.

26.5 Route IP Setup

The first step is to enable the IP routing in Menu 1 — General Setup.

To edit menu 1, type in 1 in the main menu and press [ENTER]. Set the Route IP field to Yes by pressing
[SPACE BAR].

Figure 26-5 Menu 1 General Setup

Menu 1 - General Setup

System Name= P650HW

Location= location

Contact Person's Name=
Domain Name=

Edit Dynamic DNS= No


Route IP= Yes

Bridge= No

Press ENTER to Confirm or ESC to Cancel:
