Prestige 650 Series User’s Guide

31-6

Filter Configuration

31.3 Configuring a Filter Set for the Prestige 650R and the

Prestige 650R-E

To configure a filter set, follow the steps shown next.

Step 1. Enter 21 in the main menu to display Menu 21 – Filter Set Configuration.

Figure 31-7 Menu 21 Filter Set Configuration (P650R and P650R-E)

Step 2. Type the filter set to configure (no. 1 to 12) and press [ENTER]

.

Step 3. Type a descriptive name or comment in the Edit Comments field and press [ENTER].

Step 4. Press [ENTER] at the message

Press ENTER to confirm…” to display Menu 21.4 – Filter

Rules Summary (that is, if you selected filter set 4 in menu 21).

See Figure 31-4 for the summary of the NetBIOS WAN rules and Figure 31-5 for the summary of the
NetBIOS LAN rules.

Menu 21 - Filter Set Configuration

Filter Filter
Set # Comments Set # Comments
------ ----------------- ------ -----------------
1 NetBIOS_WAN 7 _______________
2 NetBIOS_LAN 8 _______________
3 TELNET_WAN 9 _______________
4 PPPoE 10 _______________
5 FTP_WAN 11 WebSet1
6 _______________ 12 WebSet2

Enter Filter Set Number to Configure= 0

Edit Comments= N/A

Press ENTER to Confirm or ESC to Cancel:
