Prestige 650 Series User’s Guide

Firmware and Configuration File Maintenance

36-15

After the configuration upload process has completed, restart the Prestige by entering “atgo”.

36.4.10

Uploading Configuration File Via Console Port

Step 1. Select 2 from Menu 24.7 System Maintenance Upload Firmware to display Menu 24.7.2

– System Maintenance – Upload System Configuration File. Follow the instructions as
shown in the next screen.

Figure 36-18 Menu 24.7.2 as seen using the Console Port

Step 2. After the "Starting Xmodem upload" message appears, activate the Xmodem protocol on your

computer. Follow the procedure as shown previously for the HyperTerminal program. The
procedure for other serial communications programs should be similar.

Step 3. Enter “atgo” to restart the Prestige.

36.4.11

Example Xmodem Configuration Upload Using HyperTerminal

Click Transfer, then Send File to display the following screen.

Menu 24.7.2 - System Maintenance - Upload System Configuration File


To upload system configuration file:

1. Enter "y" at the prompt below to go into debug mode.

2. Enter "atlc" after "Enter Debug Mode" message.

3. Wait for "Starting XMODEM upload" message before activating

Xmodem upload on your terminal.
4. After successful firmware upload, enter "atgo" to restart the

system.

Warning:

1. Proceeding with the upload will erase the current

configuration file.
2. The system’s console port speed (Menu 24.2.2) may change

when it is restarted; please adjust your terminal's speed

accordingly. The password may change (menu 23), also.

3. When uploading the DEFAULT configuration file, the console

port speed will be reset to 9600 bps and the password to

"1234".
Do You Wish To Proceed:(Y/N)
