Prestige 650 Series User’s Guide

35-2

System Information and Diagnosis

Figure 35-2 Menu 24.1 System Maintenance : Status

The following table describes the fields present in Menu 24.1 System Maintenance Status which
are read-only and meant for diagnostic purposes.

Table 35-1 Menu 24.1 System Maintenance : Status

FIELD DESCRIPTION

Node-Lnk

This is the node index number and link type. Link types are: PPP, ENET, 1483.

Status

This shows the status of the remote node.

TxPkts

The number of transmitted packets to this remote node.

RxPkts

The number of received packets from this remote node.

Errors

The number of error packets on this connection.

Tx B/s

This shows the transmission rate in bytes per second.

Rx B/s

This shows the receiving rate in bytes per second.

Up Time

This is the time this channel has been connected to the current remote node.

My WAN IP
(from ISP)

This is the IP address of the ISP remote node.

Menu 24.1 - System Maintenance – Status hh:mm:ss

Sat. Jan. 01, 2000

Node-Lnk

1-ENET

2

3
4

5

6

7

8


Status

Up

N/A

N/A
N/A

N/A

N/A

N/A

N/A

TxPkts

211

0

0
0

0

0

0

0

RxPkts

0

0

0
0

0

0

0

0

Errors

0

0

0
0

0

0

0

0

Tx B/s

0

0

0
0

0

0

0

0

Rx B/s

0

0

0
0

0

0

0

0

Up Time

0:26:20

0:00:00

0:00:00
0:00:00

0:00:00

0:00:00

0:00:00

0:00:00

My WAN IP (from ISP) :

Ethernet:

Status: 10M/Half Duplex

Collisions: 0
CPU Load= 3.8%

WAN:

Tx Pkts: 53 Line Status: Up

Rx Pkts: 36 Upstream Speed: 0 Kbps
Downstream Speed: 0 Kbps

Press Command:

COMMANDS: 1-Reset Counters ESC-Exit
