Prestige 650 Series User’s Guide

35-8

System Information and Diagnosis

SdcmdSyslogSend (SYSLOG_PKTTRI, SYSLOG_NOTICE, String);

String = Packet trigger: Protocol=xx Data=xxxxxxxxxx…..x

Protocol: (1:IP 2:IPX 3:IPXHC 4:BPDU 5:ATALK 6:IPNG)

Data: We will send forty-eight Hex characters to the server

Jul 19 11:28:39 192.168.102.2 ZYXEL: Packet Trigger: Protocol=1,

Data=4500003c100100001f010004c0a86614ca849a7b08004a5c020001006162636465666768696a6b6c6d6e6f70717273
74

Jul 19 11:28:56 192.168.102.2 ZYXEL: Packet Trigger: Protocol=1,

Data=4500002c1b0140001f06b50ec0a86614ca849a7b0427001700195b3e00000000600220008cd40000020405b4

Jul 19 11:29:06 192.168.102.2 ZYXEL: Packet Trigger: Protocol=1,

Data=45000028240140001f06ac12c0a86614ca849a7b0427001700195b451d1430135004000077600000

3 - Filter Log

SdcmdSyslogSend (SYSLOG_FILLOG, SYSLOG_NOTICE, String);

String = IP[Src=xx.xx.xx.xx Dst=xx.xx.xx.xx prot spo=xxxx dpo=xxxx] S04>R01mD
IP[…] is the packet header and S04>R01mD means filter set 4 (S) and rule 1 (R), match (m), drop

(D).

Src: Source Address

Dst: Destination Address

prot: Protocol (“TCP”, ”UDP”, ”ICMP”)

spo: Source port
dpo: Destination port
Jul 19 14:43:55 192.168.102.2 ZYXEL: IP [Src=202.132.154.123 Dst=255.255.255.255 UDP spo=0208

dpo=0208]} S03>R01mF
Jul 19 14:44:00 192.168.102.2 ZYXEL: IP [Src=192.168.102.20 Dst=202.132.154.1 UDP spo=05d4

dpo=0035]} S03>R01mF

Jul 19 14:44:04 192.168.102.2 ZYXEL: IP [Src=192.168.102.20 Dst=202.132.154.1 UDP spo=05d4

dpo=0035]} S03>R01mF

4 - PPP Log

SdcmdSyslogSend (SYSLOG_PPPLOG, SYSLOG_NOTICE, String);
String = ppp:Proto Starting / ppp:Proto Opening / ppp:Proto Closing / ppp:Proto Shutdown
Proto = LCP / ATCP / BACP / BCP / CBCP / CCP / CHAP/ PAP / IPCP / IPXCP
Jul 19 11:42:44 192.168.102.2 ZYXEL: ppp:LCP Closing

Jul 19 11:42:49 192.168.102.2 ZYXEL: ppp:IPCP Closing

Jul 19 11:42:54 192.168.102.2 ZYXEL: ppp:CCP Closing

35.5 Diagnostic

The diagnostic facility allows you to test the different aspects of your Prestige to determine if it is working
properly. Menu 24.4 allows you to choose among various types of diagnostic tests to evaluate your system,
as shown in the following figure.

Follow the procedure next to get to Diagnostic:

Step 1. From the main menu, type 24 to open Menu 24 – System Maintenance.

Step 2. From this menu, type 4. Diagnostic to open Menu 24.4 System Maintenance Diagnostic.
